Package Contents

Item Name Quantity Description
2XL430-W250-T 1 DYNAMIXEL Servo
Robot Cable-X3P 180mm 1 TTL 3p Cable(JST-JST)
Bolt M2.5x5 10 Bolts for frame attachement
Bolt M2x5 10 Bolts for horn attachment



Supported Features



Operating Mode Description Typical Use Case
Velocity Control Mode Controls the rotational speed continuously in either direction. Wheels, rollers, or drive systems.
Position Control Mode (0–360°) Moves to and holds a specific angle within 360°. Pan-tilt mechanisms, angular joint positioning.
Extended Position Control Mode Allows multi-turn (±256 revolutions) position control. Robotic arms, winches, mechanisms requiring precise multi-rotation movement.
PWM Control Mode (Voltage Control) Directly controls the applied voltage via PWM, without position or velocity feedback. Open-loop systems, testing, or simple motor control without feedback.

Feedback Type XL430 XC430
Position ✓ ✓
Velocity ✓ ✓
PWM ✓ ✓
Input Voltage ✓ ✓
Temperature ✓ ✓
Realtime tick ✓ ✓
Trajectory ✓ ✓
